Sleeve
Front
Ledpro copyright
Connector
Please ignore these steps if the front
connector has been assembled before
delivery.
Explosive View
Finished Assembly View
1. Components of Front Connector
Anti-skidding Clip (2pcs) PC Cover (1pc) Feed Connector (1pc)
2. Installation Steps
2.1 Placing PC Cover
The wide open side faces
towards the cut edge.
Pay attention the direction of the PC cover
