4. Chasing Light Wiring

Note：
1. This LED Neon Flex must be used in conjunction with a DC24V power supply and IC-UCS2903 compatible controller or decoder.2.
Polarity symbols, GND, signal line connection should match on each component properly.
3. Ensure to add 20% buffer when sizing power supply.
4. Ensure that the power cable carried current is no greater than 80% of its capacity.
5. To minimize the voltage drop and keep light consistency, position power supply nearest to the power feed end of LED Neon Flex
and keep the power line as short as possible.
6. This is one directional. The signal input direction is always indicated by an arrow marked on the side of light.

Instructions for Chasing Light Wiring:
Red Wire Connects to the“VCC”or Anode(+) Terminal
Yellow Wire Connects to the “Signal”Terminal.
Black Wire Connects to the“GND”or Cathode(-) Terminal
