Page 7 - Series-3 Neon-Flex manual

07 Ledpro copyright

Cautions

1. Before making any cuts, installation, maintenance or
connection, be sure the mains is disconnected! 120 mm
2. All connector joints must be connected correctly to achieve
IP68 rating.
3. Please operate this flex light by instructions, and confirm the
work voltage, it must be matched with product requirements. Keep the min. bend diameter 120mm
4. Please confirm the polarity of connector before inserting
front connector and energizing the mains power.
5. Connect and cut this light correctly. Any wrong operation will
Light Surface
damage this light.
6. Using qualified DC power supply.
7. Please correctly use and bend the Neon-Flex, see the
figures on the right.
8.Do not operate light when ambient temperature exceeds the
range of specified temperature in User Manual.
9.Do not energize the light over 30 minutes in coil packaging.
10.Do not mix the four colors (R,G,B,W) in full load
simultaneoursly.

Light Surface Twist the light

Light Surface

Bend along light surface

Light Surface

Bend along light surface

WARNING: The above wrong approaches will damage the light.
